Stands for testing drive axles

Stands are intended for:

• The maintaining organizations having various rolling stock, independently carrying out various kinds of repair and having technological requirement in after-repair running in and test of drive axles;
• Autorepair factories;
• Manufacturers of drive axles;
• The service centers;
• Establishments of an average special and higher education.

By working out of stands the advanced technical decisions of “KOPIS” Ltd. and the newest technologies power- and energy saving are applied.

The newest technologies of “KOPIS” Ltd. provide to Users of stands models КС-05 and КС-051 following advantages:

• 100 % conformity to standard documents and instructions of manufacturers on after-repair running in and tests of drive axles;
• The minimum cost for the equipment of a similar class;
• Universality;
• Small power consumption;
• Reduction of expenses for the electric power and stand operation in natural and term of money more than on 50 % in comparison with the out-of-date similar equipment of the Soviet period;
• Reduction of floor spaces;
• Personnel optimization;
• The maximum automation;
• Simplicity of installation and service, convenience of using;
• Reliability and safety;
• Guarantees and service of the manufacturer – “KOPIS” Ltd.;
• Serially made equipment. Shipment term - within 14 days.

Stands made by individual orders for a running in and test of drive axles solve specific problems of the Customer, such as:

• Running in and testing drive axles of supersize technics (for example, a running in and test ВМ of career dump-body trucks of "BelAZ");
• Running in and test tractors drive axles;
• Running in and test loaders drive axles (for example, "Amkodor").

SERIALLY MADE STANDS MODELS КС-05 AND КС-051

BASIC TECHNICAL CHARACTERISTICS

Overall dimensions (length х width х height), mm:

• Stand: 2150 х 3010 х 1200;
• Electric equipment case: 625 х 605 х 1910;
• Control panel: 490 х 460 х 1160;
• Mobile refueling station with heating: 400 х 400 х 700.

Weight: КС-05 – 1200 kg; КС-051 – 1300 kg.

Established total capacity of an electric equipment: 25 kw

Power line: number of phases - 3; pressure - 380 In; frequency - 50 Hz

Quantity of attendants - 1 person

The stand is established on vibration isolating support. Special base is not required

Controllable parameters:

• Frequency of rotation of entrance shaft;
• Frequency of rotation of drums of wheels;
• Frequency of rotation of a target flange of the bridge through passage (for KAMAZ);
• Pressure in a bridge case;
• Pressure in system of pumping of wheels;
• The moment on entrance to shaft;
• Oil temperature;
• Current time of test;
• The general time of test.

Operating modes:

• Check of tightness of a case;
• Check of rotation of a flange of entrance shaft;
• Test;
• Differential test;
• Test of system of turn of wheels;
• Blocking test;
• Check of tightness of system of pumping of wheels.

Stands of model КС-05 and КС-051 are the complete equipment. It doesn't assume additional options and the additional expenses connected with it.
