Stands for testing internal manual transmissions

Application of the newest technologies of power savings provides low level of power consumption and recuperation of the electric power.

Serially made stands KS-02 and КС-021 provide after-repair runnings in and tests of the most demanded various models of manual transmissions.

Stands made by individual orders solve specific problems in the field of a running in and the tests of manual transmissions facing the Customer, such as:

• Individual requirements to parameters of loading;
• Measurement and control of the parameters set by the Customer;
• Individual requirements to formation of accounting reports of a running in.

Stands КС-02 and КС-021 are intended for the maintaining organizations having a various rolling stock, independently carrying out various kinds of repair and having technological requirement in after-repair running in and testing of manual transmissions. These are:

• Auto repair factories;
• Manufacturers;
• The service centers.

Thanks to the realized technical decisions stands кс-02 and кс-021 possess following advantages:

• The minimum cost for the equipment of a similar class;
• Universality;
• Power savings;
• Reduction of floor spaces;
• Personnel optimization;
• The maximum automation;
• Simplicity of installation and service, convenience of using;
• Reliability and safety;
• Guarantees and service of the manufacturer – “KOPIS” Ltd;
• Serially made equipment. Shipment term - within 14 days.

SERIALLY MADE STANDS MODELS КС-02 AND КС-021

BASIC TECHNICAL CHARACTERISTICS

Overall dimensions (length х width х height), mm

- Loading station: 3400 х 1000 х 830;

- Electric equipment case: 870 х 630 х 1900;

- Control panel (height х depth х width), mm: 1160 х 460 х 490.

Weight: КС-02 – 1300kg; КС-021 – 1500kg.

The established total capacity of electric equipment: 75kw

The power saving up equipment. The capacity consumed by the stand:

- In a mode «a running in without loading» - 40 kw;

- In a mode «a running in under loading» (with recuperation of the electric power) - 35 kw.

Power line: number of phases - 3; pressure - 380 In; frequency - 50 Hz

Pressure of the compressed air brought to the stand - 3... 4 kg/cm²

Quantity of attendants - 1 person

The stand is established on vibration isolating support. Special base is not required.

Controllable parameters:

• Frequency of rotation of an entrance shaft of a check point;
• Frequency of rotation of a target shaft of a check point;
• The Brake (loading) moment on the day off to a check point shaft;
• Time (duration of a running in).

Operating modes:

• Running in without loading;
• Running in under loading.

Stands of model КС-02 and КС-021 are a complete equipment. They don't assume additional options and the additional expenses connected with it.
